Karcher Puzzi 30/4 Spray Extraction Cleaner

The Karcher Puzzi 30/4, large capacity, high performance carpet and upholstery cleaner with revolutionary flexible suction tool.

Karcher Puzzi 30/4 Spray Extraction Cleaner

1-3 WORKING DAYS DELIVERY ON ALL ORDERS
*NEXT DAY DELIVERY AVAILABLE

£2468.40 (inc VAT)

£2,057.00 (excl VAT)

Part number: K1101123

Compare

► Delivery in 1-3 working days

► Don't forget to add cleaning agents.

► Or, configure the bundle selected below!

Often purchased together

Total item price: £x (inc VAT)

Kärcher’s all-new Puzzi 30/4 makes carpet and upholstery cleaning easier and more productive. Using the proven spray-extraction method but with the added advantage of Kärcher’s revolutionary flexible suction tool, the 30/4 deep cleans carpets and leaves only a market-leading 9% residual moisture. This means that carpets and upholstery are left almost completely dry, reducing the risk of resoiling and enabling cleaned areas to be used again very quickly.

The Karcher Puzzi 30/4 has a very small footprint to make storage and transportation easy, and to enable use in confined spaces. The new removable dirty tank makes emptying and refilling easy and safe.

Features and benefits

Features & Benefits

User-friendly EASY Operation operating concept
Removable wastewater container	To protect against dirt, the dirty water tank's handle is attached to the outside. The dirty water tank is easy to remove and can also be used to fill the fresh water tank. A short description on the rear of the dirty water tank explains the work process in a way that is easy to understand.
Extremely quiet	With just 66 db(A), the Puzzi 30/4 is one of the quietest wet vacuum cleaners. Thanks to the low noise volume, the machine can be used everywhere,even during business hours and in hotels. The low noise emissions protects the operator and allow longer workintervals.
For large areas
Large transport wheels
Large tank capacity	Even with a full 30-litre fresh water tank, the Puzzi 30/4 can be easily transported lying on its back. An integrated level indicator display shows the operator the currentfresh water level. The fresh water filter protects the components and can be removed without tools and cleaned.
High suction power
High cleaning performance
Height adjustable handle
Power outlet for PW 30/1	The integrated power outlet enables flexible use of the PW 30/1 without an additional power source. When not in use, the power outlet is effectively protected by an automatically closing flap. The PW 30/1 increases the area performance, cleans the pile with a rotating brush and aligns it in one direction.

Specifications

Technical data

Max. area performance (m²/h)	60 - 75
Air flow (l/s)	74
Vacuum (mbar/kPa)	254 / 25.4
Spray rate (l/min)	3
Spray pressure (bar)	4
Fresh / waste water tank (l)	30 - 15
Power rating fan (W)	1200
Power rating, pump (W)	70
Voltage (V)	220 - 240
Frequency (Hz)	50 - 60
Weight (kg)	26
Dimensions (L x W x H) (mm)	590 x 470 x 783

Equipment

Spray hose with integral water feed, 4 m
Spray suction hose (m), 4 m
Additional handle
Wide floor nozzle with flexible suction lip
