The HD 7/12-4 M Plus, a powerful, robust and versatile cold water pressure washer with good accessory storage and perfect manoeuvrability for daily operation.
1-3 WORKING DAYS DELIVERY ON ALL ORDERS
*NEXT DAY DELIVERY AVAILABLE
£1798.80 (inc VAT)
£1,499.00 (excl VAT)
Part number: K1524936
Often purchased together
Total item price: £x (inc VAT)
Powerful, versatile and robust machines, ideal for tough cleaning jobs in agriculture, construction and automotive sectors, where high water flow is needed to shift dirt and detergent quickly. The upright design makes them highly manoeuvrable and easy to transport. Equipped with quality features such as an automatic pressure relief system and and built with efficient pump technology the machine can withstand harsh industrial environments. The dirtblaster nozzle provides even greater cleaning performance for the most difficult cleaning tasks and the sophistcated on board storage allows for secure and tidy storing.
Features and benefits
FEATURES AND BENEFITS
High-quality equipment
Automatic pressure relief for protecting the components extends their service life. Powerful, 4-pole slow-running electric motor. High-quality brass cylinder head.
Flexible operation
Designed for upright and horizontal operation. Maximum stability in horizontal operation as the wheels do not touch the ground.
Outstanding mobility
Push handle can be retracted at the push of a button, thus increasing the compactness of the machine and reducing the space requirement. Effortless storage in service vehicles. Integrated storage options reduce the set-up times.Clever accessory storage
- Bracket for fixing the cup foam lance.
- EASY!Lock TR20 allows the power nozzle or a surface cleaner to be stored directly at the machine.
- Practical nozzle compartment for holding the rotary nozzle.
Easy servicing
- Easy access to the cylinder head when bottom of machine is opened.
- Fast access to electrical box through simple removal of cover.
- Large, easily accessible water fine filter for protecting the pump against dirt particles in water.
Efficient and time-saving solutions
- Effortless EASY!Force high-pressure gun.
- EASY!Lock quick-release locks: durable and robust. And five times faster than screws.
Increased energy efficiency
- Newly developed 3-piston axial pump with considerably reduced flow and pressure losses.
- 20 percent increase in cleaning performance and energy efficiency.
Specifications
Technical data
| Current type (Ph/V/Hz) | 1 / 240 / 50 |
| Flow rate (l/h) | 700 |
| Operating pressure (bar/MPa) | 120 / 12 |
| Max. pressure (bar/MPa) | 180 / 18 |
| Power rating (kW) | 3.1 |
| Power cable (m) | 5 |
| Weight (with accessories) (kg) | 41.3 |
| Weight incl. packaging (kg) | 44.6 |
| Dimensions (L x W x H) (mm) | 400 x 455 x 700 |
Equipment
- Trigger gun, EASY!Force
- High-pressure hose, 10 m
- Spray lance, 840 mm
- Power nozzle
- Dirt Blaster spray lance
- Pressure switch control
- Quick coupling
Accessories
600 mm stainless steel lance (manual coupling) with ergonomic handle for ease of use and protection. Rotatable 360° under pressure.
For hard-to-reach areas: High-pressure articulated joint with infinite angle adjustment up to 120°. Simply attach directly to the spray lance of the pressure washer.
10 m high-pressure hose (M 22 x 1.5) with kink protection. With patented rotating AVS trigger gun connector and manual coupling. Further data: DN 6/155°C/250 bar.
20 m high-pressure hose (M 22 x 1.5) with kink protection. With patented rotating AVS trigger gun connector and manual coupling. Further data: DN 8/155°C/315 bar.
Brass double connector for connecting and extending high-pressure hoses. With rubber protection. Connector: 2x M 22 x 1.5 m.
For high-pressure cleaners with a flow rate of 700–800 l/h: new, robust and very high-quality foam cup lance with outstanding foam quality while consuming half as much cleaning agent.
Cleaning Agents
For optimal protection of hot water high-pressure cleaners with System Care option. System Care Advance 2 provides the following protection functions for your equipment:– Protection against limescale deposits in the heating coil (up to 150°C) – Pump care additive for continuous lubrication and care of the high-pressure pump – Protection against black water contamination (rust formation in the heating coil in the case of very soft water) – Corrosion protection for all parts in contact with water.
Scale inhibitor for hot water high-pressure cleaners with integral corrosion protection, especially for use in new HDS units with System Care option. The System Care Advance 1 RM 110 ASF formula offers improved protection against limescale deposits on heater coils (up to 150 °C) and provides integral corrosion protection for components in contact with water.
Powerful facade cleaner with gel formula. Removes soot, oil, grease and environmental stains. Suitable for façades clad with stone, brick, rough-cast plaster, plastic, wood and glass.
Powerful deep cleaner effectively removes the most stubborn stains, such as oil, grease, soot, blood and proteins. Low foam production. Particularly suited for floor cleaning by machine and for processing with hard surface cleaners. NTA free.
Removes even the toughest grease, protein, oil and soot soiling from floors, working surfaces, machines, etc. (particularly suitable for food processing operations). Easy to use, gentle cleaning action. Washes clean without residue.
The alkaline Foam Cleaner RM 838 is for contactless vehicle washing which effortlessly removes heavy oil and grease stains, insect residues and road dirt and is gentle on paintwork.
